CUSTOMER ORIENTED,SERVING FARMERS
7 Years
| Ask Lasest Price | |
| Brand Name : | PRESUN |
| Model Number : | 5HPX-15 |
| Certification : | ISO |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 100 sets per month |
| Delivery Time : | 5-8 working days if no customization parts |
Paddy Dryer Machine Feature:
Low speed mixing, anti-broken elevator, grain broken rate low, good drying quality
Vertical large-size four-slot and large amount of air drying layer with high drying efficiency
Automatic intelligent electronic control system, the operation is easier
Optional imported online grain moisture meter to achieve accurate detection of grain moisture
Multiple heating method and fuels options with low drying costs
Paddy Dryer Machine Working Principle :
1. Paddy Loading
The Paddy is raised to the top of the main engine silo through the hoist, and the grain is put into the drying box through the agitating device until it is full.
2. Running:
The elevator is running all the time. When the Paddy reaches the bottom under the action of self-weight, the elevator raises the Paddy to the top and dries slowly from top to bottom
3. Drying:
The hot air passes through the drying layer horizontally. The grain is fully contacted with the drying layer after heating, and achieved drying effect.
Essential Motor Lists :
| No. | Description | Power | Qty | In Total | |
| 1 | Elevator | 2.2 | 1 | 2.2 | |
| 2 | Lower Screw Conveyor | 1.5 | 1 | 1.5 | |
| 3 | Spreader | 0.55 | 1 | 0.55 | |
| 4 | Dust Removal | 0.55 | 1 | 0.55 | |
| 5 | Exhaust Blower | 5.5 | 1 | 5.5 | |
| 6 | Rotary Valve | 1.1 | 1 | 1.1 | |
| In Total | 6 | 9.95 | |||
Applications:
|
|
